Digital Pendulum Impact Tester for Film and Paper Packaging

Digital Pendulum Impact Tester for Film and Paper Packaging
Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging Digital Pendulum Impact Tester for Film and Paper Packaging

Duży Obraz :  Digital Pendulum Impact Tester for Film and Paper Packaging

Szczegóły Produktu:
Miejsce pochodzenia: CHINY
Nazwa handlowa: Haida
Orzecznictwo: CE、ISO
Numer modelu: 5086-HD
Zapłata:
Minimalne zamówienie: 1 zestaw
Cena: negocjowalne
Szczegóły pakowania: każdy zestaw zabezpieczony włóknem żywicznym i folią PP, a następnie umieszczony w mocnej drewnianej
Czas dostawy: 20 dni po potwierdzeniu zamówienia
Zasady płatności: L/C, D/A, D/P, T/T, Western Union, Moneygram
Możliwość Supply: 300 zestawów miesięcznie

Digital Pendulum Impact Tester for Film and Paper Packaging

Opis
Funkcjonować: Test kompresji, test wytrzymałości na ściskanie papieru, tester serii, test rozciągania, przyrząd do Nazwa: Tester wytrzymałości na ściskanie na miseczkach papieru, testowiec testowy papierowy tester GSM/ tes
Wyświetlacz: LCD, wyświetlacz cyfrowy Jednostki przełączają się: KGF, n. (Opcjonalnie), LBF
Stalowa piłka: 16 mm * 20 Zakres częstotliwości: 60-300 okrągły/min regulowany
Tryb napędu: napędzane silnikiem Metoda wskazująca: Cyfrowy
Przestrzeń testowa: 600 × 800 × 800 mm (można dostosować) Zakres wysokości spadku: 400-1500mm
Wymiar: 530 (l)* 490 (d)* 960 (h) mm Zakres pomiaru: 0~199
Dostosowane wsparcie: OEM ODM Długość łzy: 43 mm
Obszar testowy: 7,3 cm² Tryb pracy: PC
Wysokość zrzutu: 400~1300 mm Prędkość podnoszenia: 50-300mm/min, ustaw stałą prędkość
Przedmioty testowe: Siła pękająca, wytrzymałość na kompresję, wytrzymałość na łzanie, odporność na nakłucie, współczynni Dokładność: ± 0,5% wartości odczytu
Precyzja: ≤0,5%
Podkreślić:

Film Paper Packaging Tester

,

Digital Pendulum Impact Tester

EQUIPMENT DETAILS FOR 5086- HD FILM PENDULUM IMPACT TESTER
Product Specifications
Attribute Value
Function Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument
Display LCD, Digital display
Units switch Kgf, N. (Optional), Lbf
Steel Ball 16mm * 20
Frequency Range 60-300 round/min adjustable
Drive Mode Power-driven
Test Space 600×800×800mm (can be customized)
Drop Height Range 400-1500mm
Dimension 530(L)*490(D)*960(H)mm
Measurement Range 0~199
Customized Support OEM ODM
Tear Length 43mm
Test Area 7.3 cm²
Operation Mode PC
Lifting Speed 50-300mm/min, set fixed speed
Test Items Bursting strength, compression strength, tearing strength, puncture resistance, friction coefficient, etc.
Accuracy ±0.5% of reading value
Precision ≤0.5%
Product Description
The 5086-HD Film Pendulum Impact Tester uses a standard pendulum head and weighted pendulum arm to measure impact resistance of plastic films, sheets, and composite films. It evaluates impact toughness for materials including PE/PP composite films, aluminized films, aluminum-plastic composites, nylon films, and materials used in food/medicine packaging. Also suitable for testing pendulum impact resistance of paper and paperboard products.
Testing Principle
The instrument uses a semi-spherical punch to impact and break samples at controlled speeds, measuring the energy consumed during impact. This energy measurement provides the anti-pendulum impact energy value for film samples.
Design Standards
Complies with GB/T8809 and ASTM D3420 standards.
Technical Parameters
Item Description
Capacity 3J
Scale value 0.01J
Pendulum swing radius R280 mm
Pendulum angle 90°
Impact speed 2.5m/S
Impact head size Φ12.7 mm
Sample holder diameter Φ60, Φ89mm
Sample size 100 X 100 mm
Dimensions 780 X 250 X 600 mm
Weight 35kg
Digital Pendulum Impact Tester for Film and Paper Packaging 0 Digital Pendulum Impact Tester for Film and Paper Packaging 1 Digital Pendulum Impact Tester for Film and Paper Packaging 2
About Haida
Haida products serve diverse industries including paper goods, packaging, printing, adhesives, textiles, footwear, leather, environmental materials, toys, hardware, electronics, plastics, and rubber. Our testing equipment meets UL, ASTM, JIS, GB, and ISO standards and is widely used by research institutions, quality inspection agencies, and academic facilities.
